Specification
What's included:
• Lamp Holder with 2x Carbon-2 DRIVE (Yellow Dip) pre-mounted (LH/RH)
• Lamp Holder Bezel (LH/RH)
• Positioning Templates (LH/RH)
• Two-Lamp Wiring Kit
• Black T-25 Torx Security Screws (x10) & Security Bit
• VHB Cleaning Sachet (x2)
| Technical specifications, x2 Carbon-2 DRIVE (Yellow Dip): | ||
| Voltage Range | 10-32V | |
| LED Life | 50,000 hours | |
| Weight | 2x 192g | |
| HIGH BEAM FUNCTION | ||
| Total Luminous Flux | 6,240 Lm | |
| Colour Temperature | 5000k | |
| Power Consumption | 58 Watts | |
| Current Draw (at 14.4V) | 4.2 Amps | |
| CERTIFICATION | ||
| High Beam | ECE R149 | |
| ECE Reference | 2x 12.5 | |
| Photometric data | ||
| 0.25 lx Line | 748 metres | |
| 0.5 lx Line | 529 metres | |
| 1 lx Line | 374 metres | |
| 3 lx Line | 216 metres | |
| Beam spread | ||
| Horizontal | 60 degree spread | |
| Vertical | 12 degree spread | |
